XT300
XT300 - Piston Seal
XT300 piston seal is a single-acting piston seal with a design that can operate safely in systems with long strokes, high pressure and high extrusion gaps compared to conventional urings.
Advantages
Area of Application
Advantages
• Superior static (locking) and dynamic sealing effect
• High extrusion resistance
• Thin oil film
• High wear resistance
• High extrusion resistance
• Thin oil film
• High wear resistance
Area of Application
• Construction machinery
• Loading platforms
• Injection moulding machines
• Forklifts
• Mobile machinery
• Agricultural machinery
• Loading platforms
• Injection moulding machines
• Forklifts
• Mobile machinery
• Agricultural machinery
Material
Code
Pressure
(max) bar
(max) bar
Temperature
(max) °C
(max) °C
Sliding Speed
(max)- m/s
(max)- m/s
PU
PU9414
400
-35/+110
0.5
| D (H9) | d (h10) | L (+0.2/-0) | H | C | MATERIAL | Kastaş CODE | ||
|---|---|---|---|---|---|---|---|---|
| XT300-040 | 40 | 30 | 7 | 6 | 2.5 | PU9401 | 10043112 | |
| XT300-045 | 45 | 35 | 7 | 6 | 2.5 | PU9401 | 10043148 | |
| XT300-050 | 50 | 40 | 7 | 6 | 2.5 | PU9401 | 10043149 | |
| XT300-055 | 55 | 45 | 7 | 6 | 2.5 | PU9401 | 10043150 | |
| XT300-056 | 56 | 46 | 7 | 6 | 2.5 | PU9401 | 10043151 | |
| XT300-060 | 60 | 50 | 7 | 6 | 2.5 | PU9401 | 10043152 | |
| XT300-063 | 63 | 53 | 7 | 6 | 2.5 | PU9401 | 10042523 | |
| XT300-065 | 65 | 55 | 7 | 6 | 2.5 | PU9401 | 10043153 | |
| XT300-066 | 66 | 56 | 7 | 6 | 2.5 | PU9401 | 10043154 | |
| XT300-070 | 70 | 60 | 7 | 6 | 2.5 | PU9401 | 10043155 | |
| XT300-071 | 71 | 61 | 7 | 6 | 2.5 | PU9401 | 10043156 | |
| XT300-073 | 73 | 63 | 7 | 6 | 2.5 | PU9401 | 10043157 | |
| XT300-075 | 75 | 65 | 7 | 6 | 2.5 | PU9401 | 10043158 | |
| XT300-077 | 77 | 67 | 7 | 6 | 2.5 | PU9401 | 10043159 | |
| XT300-080 | 80 | 70 | 7 | 6 | 2.5 | PU9401 | 10043160 | |
| XT300-085 | 85 | 75 | 7 | 6 | 2.5 | PU9401 | 10043161 | |
| XT300-090 | 90 | 80 | 7 | 6 | 2.5 | PU9401 | 10043162 | |
| XT300-100 | 100 | 85 | 10 | 9 | 4 | PU9401 | 10043163 | |
| XT300-105 | 105 | 90 | 10 | 9 | 4 | PU9401 | 10043164 | |
| XT300-110 | 110 | 95 | 10 | 9 | 4 | PU9401 | 10043165 | |
| XT300-115 | 115 | 100 | 10 | 9 | 4 | PU9401 | 10043166 | |
| XT300-120 | 120 | 105 | 10 | 9 | 4 | PU9401 | 10043167 | |
| XT300-125 | 125 | 112 | 10 | 9 | 4 | PU9401 | 10043168 | |
| XT300-130 | 130 | 115 | 10 | 9 | 4 | PU9401 | 10043169 | |
| XT300-140 | 140 | 125 | 10 | 9 | 4 | PU9401 | 10043170 | |
| XT300-150 | 150 | 135 | 10 | 9 | 4 | PU9401 | 10043171 |
